Figure 6-3 Networking for the VPLS enterprise private line service
VPLS
VPLS PW
Branch A
Branch B
Branch C
CE
PW2
(Master)
PW3
(Slave)
PE3 (CX600)
PE2 (CX600)
OLT/MSAN
PE1
PE4
PW1
PW4
Prerequisite
QinQ traffic streams have been configured on PE1-PE4 for the private line service of different
branch offices.
NOTE
To configure the Ethernet-based enterprise private line service, you must configure QinQ VLAN-based Ethernet
traffic streams on PE1-PE4, and perform corresponding configurations on routers for branch offices of the
enterprise. The configurations are the same as those for common QinQ VLAN private line service, which are
not described here.
Data Plan
Table 6-4 provides the key data plan for the OLT/MSAN (MA5600T/MA5603T/MA5608T).
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 6 Configuration Example of VPLS
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
500
