3. Configure the media IP address pool and the signaling IP address pool.
huawei(config)#voip
huawei(config-voip)#ip address media 10.176.6.33 10.176.6.62
huawei(config-voip)#ip address signaling 10.176.6.33
4. Configure the MG interface.
Add an MG interface.
huawei(config)#interface h248 0
Are you sure to add MG interface? (y/n)[n]:y
Configure the MG interface attributes.
huawei(config-if-h248-0)#if-h248 attribute mgip 10.176.6.33 mgport 2944 code
text
transfer udp primary-mgc-ip1 10.30.80.65 primary-mgc-port 2944 mg-media-ip1
10.176.6.33
Configure the software parameters of the MG interface (in this example, only parameter
20 is configured, and other parameters use the default values).
huawei(config-if-h248-0)#mg-software parameter 20 2
5. Reset the MG interface.
NOTE
After configuring the MG interface, you need to reset the interface to validate the configuration.
huawei(config-if-h248-0)#reset coldstart
Are you sure to reset MG interface?(y/n)[n]:y
6. Add PSTN users in batches.
huawei(config)#esl user
huawei(config-esl-user)#mgpstnuser batadd 0/3/0 0/3/31 0 terminalid 0 telno
88660032
Step 11 Configuring the QinQ private line service.
MA5600T-1 and MA5600T-4 serve two branches of a company to provide the QinQ private
line service.
1. Create VLAN 50.
huawei(config)#vlan 50 mux
2. Set VLAN 50 as QinQ VLAN.
huawei(config)#vlan attrib 50 q-in-q
3. Add the upstream port.
huawei(config)#port vlan 50 0/19 0
4. Add the service port.
To add the service port, run the service-port command. Note that the VPI and VCI values
of the virtual port must be the same as those on the modem.
The QinQ VLAN supports the PVC-priority scheduling policy only. In this case, select the
profile that supports PVC-priority policy.
huawei(config)#traffic table ip index 7 cir off priority 0 priority-policy
local-Setting
huawei(config)#service-port vlan 50 shdsl 0/5/15 vpi 0 vci 35 rx-cttr 7
tx-cttr 7
Step 12 Configure the multicast service.
After the configuration, the following results should be achieved:
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
7 Example: Subtending Networking
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
518
