Data Plan
Item Data
ONT line profile Profile name: ftth
T-CONT ID: 4
GEM port ID for Internet access service: 14
Network topology data Upstream port: 0/19/0
PON port: 0/1/0
ONT IDs: 1 and 2
ID of the port on the HGW that is connected to the PC: 1
VLAN Plan Double-tagged VLAN:
l S-VLAN ID: 100
l S-VLAN type: smart
l S-VLAN attribute: stacking
l C-VLAN ID: 1001-1002
l U-VLAN ID: 45
VLAN translation policy:
l ONT: The upstream packets sent from the HGW carry
user-VLANs and the ONT transparently transmits them.
l OLT: The OLT translates the U-VLAN to S-VLAN+C-
VLAN.
Procedure
l Configure the OLT.
1. Configure a traffic profile.
Run the display traffic table ip command to query existing traffic profiles in the
system. If the traffic profiles existing in the system do not meet the requirements, you
need to run the traffic table ip command to add a traffic profile.
Set the profile ID to ftth_hsi, the CIR to 4 Mbit/s, and the priority to 0. In addition,
configure the scheduling mode so that packets are scheduled according to their
priorities.
huawei(config)#traffic table ip name ftth_hsi cir 4096 priority 0 priority-
policy local-setting
2. Configure the mapping between a GEM port and a VLAN.
The service flow of user-side VLAN 45 is mapped to GEM port 14 in the ONT line
profile.
NOTE
Here, the user-side VLAN is the VLAN carried by packets sent from HGW to ONT, namely, U-
VLAN.
huawei(config)#ont-lineprofile gpon profile-name ftth
huawei(config-gpon-lineprofile-1)#gem mapping 14 0 vlan 45
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
9 FTTH Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
636
