Item Data
VLAN plan Single VLAN tag:
l VLAN ID: 300
l VLAN type: smart
l VLAN attribute: common
l UVLAN ID: 47
VLAN translation policy:
l ONT: Packets that are sent upstream by the HGW are
tagged with a user VLAN. The ONT transparently
transmits the user VLAN.
l OLT: translates the VLAN tag (user VLAN <-> S-
VLAN).
Voice parameter
IP address of the SIP server: 200.200.200.200/24
Port ID of the SIP server: 5060
User phone number: 77730010
Procedure
l Configure the OLT.
1. Configure a traffic profile.
Run the display traffic table ip command to query the existing traffic profiles in the
system. If the existing traffic profiles in the system do not meet the requirements, run
the traffic table ip command to add a traffic profile.
Set the profile name to ftth_voip and do not limit the upstream and downstream rates.
Set the priority to 5 and packets are scheduled according to the priority carried.
huawei(config)#traffic table ip name ftth_voip cir off priority 5 priority-
policy
local-setting
2. Configure the mapping relationship between a GEM port and a VLAN.
The service flow of user VLAN 47 is mapped to GEM port 12 in the ONT line profile.
NOTE
The user VLAN is the VLAN in the packets sent from the HGW to the ONT, that is, the UVLAN.
huawei(config)#ont-lineprofile gpon profile-name ftth
huawei(config-gpon-lineprofile-1)#gem mapping 12 2 vlan 47
huawei(config-gpon-lineprofile-1)#commit
huawei(config-gpon-lineprofile-1)#quit
3. Configure the VLAN of the Ethernet port on the ONT.
If the ONT is connected to the HGW through Ethernet port 1, add Ethernet port 1 to
VLAN 47 in the ONT service profile.
huawei(config)#ont-srvprofile gpon profile-name ftth
huawei(config-gpon-srvprofile-1)#port vlan eth 1 47
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
9 FTTH Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
639
