l The configuration processes on HGWs of different models or in different appearances are
similar. This topic describes how to configure the Internet access service on an HG239 that
is connected to an ONT upstream through a LAN.
Data Plan
Item Data
ONT line profile Profile name: ftth
T-CONT ID: 4
GEM port ID: 13
Traffic profile ID: 8
802.1p priority: 4
CIR: off (unlimited)
Priority-based scheduling policy: local-setting
VLAN Plan Single VLAN tag:
l SVLAN ID: 1000
l HGW VLAN: 43
l MVLAN ID: 1000
l VLAN type: smart
l VLAN attribute: common
VLAN translation policy:
l ONT: translates the upstream VLAN of the HGW to an
MVLAN.
l OLT: duplicates multicast packets based on PON ports
with MVLAN unchanged.
Multicast service data
Multicast protocol: IGMP proxy
Multicast version: IGMPv2
Multicast program: dynamic obtaining mode
Procedure
l Configure the OLT.
1. Configure a traffic profile.
Configure traffic profile 8. Set the CIR to off (unlimited), priority to 4, and priority-
based scheduling policy to local-setting (that is, queues are scheduled based on the
priority specified in the profile).
NOTE
Run the display traffic table ip command to query the existing traffic profiles in the system. If the
existing traffic profiles in the system do not meet the requirements, run the traffic table ip command
to add a traffic profile.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
9 FTTH Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
642
