Prerequisites
l The interface data and POTS user configuration data corresponding to the MG interface
have been configured on the MGC.
l The OLT has been connected to the MGC. The OLT can ping the IP address of the MGC
server successfully.
l The ONT has been added to the OLT. For details, see 9.7.1.3 Adding an ONT to an
OLT.
l Different voice services require different ONT software versions. Before the configuration,
ensure that the current ONT software version supports H.248. For details, see relevant ONT
manuals.
Context
Item Data
ONT line profile Profile name: ftth
T-CONT ID: 4
GEM port ID: 12
VLAN Plan Single VLAN tag:
l SVLAN ID: 200
l SVLAN type: smart
l SVLAN attribute: common
l CVLAN ID: 300
VLAN translation policy:
l ONT: VLANs are configured for the ONTs on the same
network in a unified manner, and the ONTs have the
same C-VLAN. The ONT adds a C-VLAN tag to
packets.
l OLT: translates the VLAN tag (C-VLAN <-> S-VLAN).
Voice parameter
IP address of the MGC server: 200.200.200.200/24
Port ID of the MGC server: 2944
MG Domain: 0100000001 or 0100000002
Procedure
l Configure the OLT.
1. Configure a traffic profile.
Run the display traffic table ip command to query the existing traffic profiles in the
system. If the existing traffic profiles in the system do not meet the requirements, run
the traffic table ip command to add a traffic profile.
Set the profile name to ftth_voip and do not limit the upstream and downstream rates.
Set the priority to 5 and packets are scheduled according to the priority carried.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
9 FTTH Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
670
