Configuration Item Data Item Data
VoIP service SVLAN: 200
CVLAN: 3
IPTV service data Multicast protocol IGMP proxy
Multicast version IGMP V3
Configuration mode of the
multicast program
Static configuration mode
IP address of the multicast
server
10.10.10.10
Multicast DHCP server group 20.2.2.2
20.2.2.3
Multicast program BTV-1: 224.1.1.10
BTV-2: 224.1.1.20
QoS (priority) HSI service Priority: 1; queue scheduling:
WRR
IPTV service Priority: 4; queue scheduling:
WRR
VoIP service Priority: 5; queue scheduling:
PQ
VoIP service data VoIP DHCP server group 20.1.1.2
20.1.1.3
Prerequisite
l The OLT is connected to the upper-layer devices such as the BRAS, multicast server,
SoftX3000, and DHCP server.
l The VLAN of the LAN switch port connected to the OLT is the same as the upstream
VLAN of the OLT.
l The OLT uses the OPFA board or the OPGD board to connect to the ONT.
Procedure
l Configure the Internet access service on the OLT.
1. Create a VLAN and add an upstream port to the VLAN.
The VLAN ID is 100, and the VLAN is a smart VLAN. The upstream port is
0/19/0.
huawei(config)#vlan 100 smart
huawei(config)#port vlan 100 0/19 0
2. Configure a traffic profile.
Because the VoIP, IPTV, and Internet access services are provided through the same
port, you must set the 802.1p priority of each service. Generally, the priorities are in
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
9 FTTH Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
718
