huawei(config)#service-port vlan 200 eth 0/5/3 multi-service user-vlan 3
rx-cttr 8 tx-cttr 8
4. Configure the DHCP relay.
The VoIP service and the IPTV service are provided in the DHCP mode. The DHCP
option 60 domain is used to differentiate service types.
– The DHCP domain of the VoIP service is voice.
– The IP addresses of VoIP DHCP server group 1 are 20.1.1.2 and 20.1.1.3.
– The IP address of the Layer 3 interface of VLAN 200 is 10.1.1.1/24.
– The gateway IP address of the DHCP domain is 10.1.1.1/24.
huawei(config)#dhcp mode layer-3 option-60
huawei(config)#dhcp-server 1 ip 20.1.1.2 20.1.1.3
huawei(config)#dhcp domain voice
huawei(config-dhcp-domain-voice)#dhcp-server 1
huawei(config-dhcp-domain-voice)#quit
huawei(config)#interface vlanif 200
huawei(config-if-vlanif200)#ip address 10.1.1.1 24
huawei(config-if-vlanif200)#dhcp domain voice gateway 10.1.1.1
huawei(config-if-vlanif200)#quit
NOTE
The DHCP option 60 domain of the Ethernet phone (Ephone) varies with the terminal type. In the
actual configuration, see the operation instructions of the Ephone.
5. Save the data.
huawei(config)#save
l Configure the IPTV service on the OLT.
1. Create a VLAN and add an upstream port to the VLAN.
The VLAN ID is 1000, and the VLAN is a smart VLAN. The upstream port
is0/19/0.
huawei(config)#vlan 1000 smart
huawei(config)#port vlan 1000 0/19 0
2. Configure a traffic profile.
The traffic profile index is 9, and the 802.1p priority of the IPTV service is 5.
huawei(config)#traffic table ip index 9 cir off priority 5 priority-
policy
local-Setting
3. Configure a service port.
Add a service port to the VLAN and use traffic profile 9. The user-side VLAN ID is
4.
huawei(config)#service-port 200 vlan 1000 eth 0/5/2 multi-service user-
vlan 4
rx-cttr 9 tx-cttr 9
huawei(config)#service-port 300 vlan 1000 eth 0/5/3 multi-service user-
vlan 4
rx-cttr 9 tx-cttr 9
4. Configure the DHCP relay.
The VoIP service and the IPTV service are provided in the DHCP mode. The DHCP
option 60 domain is used to differentiate service types.
– The DHCP domain of the IPTV service is video.
– The IP addresses of IPTV DHCP server group 2 are 20.2.2.2 and 20.2.2.3.
– The IP address of the Layer 3 interface of VLAN 1000 is 10.2.2.1/24.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
9 FTTH Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
720
