Item Data
VLAN plan Single VLAN tag:
l VLAN ID: 300
l VLAN type: smart
l VLAN attribute: common
l CVLAN=SVLAN
VLAN translation policy:
l ONU: provides the VoIP service and uses the same
SVLAN.
Voice parameter IP address of the SIP server: 200.200.200.200/24
Port ID of the SIP server: 5060
Home domain name: huawei.com
User phone number 1: 77730010
User phone number 2: 77730020
Procedure
Step 1 Configure a traffic profile.
Run the display traffic table ip command to query the existing traffic profiles in the system. If
the existing traffic profiles in the system do not meet the requirements, run the traffic table ip
command to add a traffic profile.
Step 2 Configure the mapping between a GEM port and a VLAN.
The service flow of user VLAN 300 is mapped to GEM port 12 in the ONU line profile.
huawei(config)#ont-lineprofile gpon profile-name fttd
huawei(config-gpon-lineprofile-1)#gem mapping 12 2 vlan 300
huawei(config-gpon-lineprofile-1)#commit
huawei(config-gpon-lineprofile-1)#quit
Step 3 Create a service VLAN and add an uplink port to it.
Add uplink port 0/19/0 to VLAN 300.
huawei(config)#vlan 300 smart
huawei(config)#port vlan 300 0/19 0
Step 4 Create service flows.
Set the service VLAN to 300, GEM port ID to 12, and user VLAN to 300, and use traffic profile
fttd_voip.
huawei(config)#service-port vlan 300 gpon 0/1/0 ont 1 gemport 12 multi-service
user-vlan 300 inbound traffic-table name fttd_voip outbound traffic-table name
fttd_voip
huawei(config)#service-port vlan 300 gpon 0/1/0 ont 2 gemport 12 multi-service
user-vlan 300 inbound traffic-table name fttd_voip outbound traffic-table name
fttd_voip
