Item Data
Traffic profile ID: 8
802.1p priority: 4
CIR: off (unlimited)
Priority-based scheduling policy: local-setting
VLAN Plan Single VLAN tag:
l SVLAN ID: 1000
l HGW VLAN: 43
l MVLAN ID: 1000
l VLAN type: smart
l VLAN attribute: common
VLAN translation policy:
l ONU: translates the user VLAN tags carried in the
upstream packets sent from the HGW to MVLAN tags.
l OLT: duplicates multicast packets based on PON ports
with MVLAN unchanged.
Multicast service data
Multicast protocol: IGMP proxy
Multicast version: IGMPv2
Multicast program: dynamic obtaining mode
Procedure
l Configure the OLT.
1. Configure a traffic profile.
Configure traffic profile 8. Set the CIR to off (unlimited), priority to 4, and priority-
based scheduling policy to local-setting (that is, queues are scheduled based on the
priority specified in the profile).
NOTE
Run the display traffic table ip command to query the existing traffic profiles in the system. If the
existing traffic profiles in the system do not meet the requirements, run the traffic table ip command
to add a traffic profile.
huawei(config)#traffic table ip index 8 cir off priority 4 priority-
policy
local-setting
2. Configure the mapping relationship between a GEM port and a VDSL2 port on the
ONU.
In the ONU line profile, the service flow of the VDSL2 port is mapped to GEM port
13.
huawei(config)#ont-lineprofile gpon profile-name fttd
huawei(config-gpon-lineprofile-1)#gem mapping 13 1 vlan 1000
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
10 FTTD Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
776
