Data Plan
Item Data
ONU line profile Profile name: fttd
T-CONT ID: 4
GEM port ID for Internet access service: 14
Network topology data Uplink port: 0/19/0
PON port: 0/1/0
ONU IDs: 1
ID of the port on the HGW that is connected to the PC: 1
VLAN Plan Double-tagged VLAN:
l S-VLAN ID: 100
l S-VLAN type: smart
l S-VLAN attribute: stacking
l C-VLAN ID: 1001-1002
l U-VLAN ID: 45
VLAN translation policy:
l ONU: transparently transmits the user VLAN tags
carried in the upstream packets sent from the HGW.
l OLT: translates the user VLAN tags to S-VLAN+C-
VLAN tags.
Procedure
l Configure the OLT.
1. Configure a traffic profile.
Configure traffic profile 8. Set the CIR to off (unlimited), priority to 4, and priority-
based scheduling policy to local-setting (that is, queues are scheduled based on the
priority specified in the profile).
NOTE
Run the display traffic table ip command to query the existing traffic profiles in the system. If the
existing traffic profiles in the system do not meet the requirements, run the traffic table ip command
to add a traffic profile.
huawei(config)#traffic table ip index 8 name fttd_hsi cir off priority 4
priority-policy local-setting
2. Configure the mapping between a GEM port and a VLAN.
The service flow of user-side VLAN 45 is mapped to GEM port 14 in the ONU line
profile.
NOTE
Here, the user-side VLAN is the VLAN carried by packets sent from HGW to ONU, namely, U-
VLAN.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
10 FTTD Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
798
