If the ONU is connected to the HGW through VDSL2 port 1, add VDSL2 port 1 to VLAN
43.
huawei(config)#ont-srvprofile gpon profile-name fttd
huawei(config-gpon-srvprofile-1)#port vlan vdsl 1 43
huawei(config-gpon-srvprofile-1)#commit
huawei(config-gpon-srvprofile-1)#quit
4. Create a service VLAN and add an upstream port to it.
Add upstream port 0/19/0 to VLAN 1100.
huawei(config)#vlan 1100 smart
huawei(config)#port vlan 1100 0/19 0
5. Create service flows.
Set the service VLAN to 1100, GEM port ID to 13, and user VLAN to 43, and use traffic
profile 8.
huawei(config)#service-port 3 vlan 1100 gpon 0/1/0 ont 1 gemport 13
multi-service user-vlan 43 rx-cttr 8 tx-cttr 8
6. Save the data.
huawei(config)#save
Step 2 Configure the HGW.
1. Log in to the web configuration window.
a. Enter http://192.168.1.1/cu.html (default IP address) to the address bar of the IE
browser and press Enter.
b. In the login dialog box, enter the user name and password of the administrator (the
Internet service provider (ISP) provides the default user name and default password).
Then, click OK.
2. Set parameters for the VoD service.
This example assumes LAN4 as an VoD port.
a. Choose Network > Bandwidth Configuration from the navigation tree.
b. In the right pane, create LAN connection 4 for the VoD service. Set the parameters
as follows:
Parameter Value
Bearing service OTHER: The connection is used for the VoD service.
VLAN
enabling
Enable VLAN tags are added to upstream packets.
NOTE
When VoD service flows are created on the OLT, the value is Disable if
uservlan is untagged and the value is Enable if uservlan is tagged.
VLANID
[1-4094]
VLAN ID corresponding to the user VLAN value for VoD
service flows created on the OLT. In this example, set this
parameter to 43.
Binding item LAN4
Mode Bridge
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 10 FTTD Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
809
