Figure 11-4 Configuration Roadmap Diagram in the FTTB and FTTC Networking Scenarios
Using LAN Access Without HGWs
The following table lists the detailed description steps..
Item Procedure Remarks
OLT Add an ONU to the OLT. Services can be configured for an ONU only
after the ONU is successfully added to an
OLT.
Configure the management
channel between the OLT and the
ONU.
After the inband management channel
between the OLT and the ONU is
configured and available, you can log in to
the ONU from the OLT to configure the
ONU.
Configure the
service channel
between the
OLT and the
ONU.
l Configure
the Internet
access
service
channel.
l Configure
the VoIP
service
channel.
The ONU provides only the Internet access
service and the VoIP service in the FTTB
and FTTC network using xDSL access
without HGWs. Therefore, you need to
create an Internet access service channel and
a VoIP service channel on the OLT.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
859
