1. Create an upstream VLAN.
The VLAN ID is 200 and the VLAN is a smart VLAN.
huawei(config)#vlan 200 smart
2. Add the upstream port to the created upstream VLAN.
Add upstream port 0/0/1 to VLAN 2000.
huawei(config)#port vlan 200 0/0 1
3. Configure the IP address of the Layer 3 interface.
Enter the VLAN interface mode and configure the lP address of the Layer 3 interface to
10.10.10.10
huawei(config)#interface vlanif 200
huawei(config-if-vlanif200)#ip address 10.10.10.10 24
huawei(config-if-vlanif200)#quit
Step 3 Configure the media and signaling IP address pools.
Configure both the media IP address and signaling IP address to 10.10.10.10 and the MG IP
address to 10.10.10.1.
huawei(config)#voip
huawei(config-voip)#ip address media 10.10.10.10 10.10.10.1
huawei(config-voip)#ip address signaling 10.10.10.10
huawei(config-voip)#quit
NOTE
l You can configure the attributes of the MG interface only when the media IP address and the signaling
IP address exist in the media and signaling IP address pools.
l The media IP address can be different from the signaling IP address. Plan the data according to actual
networking.
Step 4 Configure static routes.
Because the IP address of the VLAN interface and the IP address (200.200.200.200/24) of the
MGC are in different network segments, you need to configure a route for the network segment
from gateway 10.10.10.1 to 200.200.200.0.
huawei(config)#ip route-static 200.200.200.0 24 10.10.10.1
Step 5 Add an MG interface.
Add an MG interface to communicate with the MGC, which ensures that the MGC can control
the call connection through the MG interface. Add MG interface 0 according to the data plan.
huawei(config)#interface h248 0
Are you sure to add MG interface?(y/n)[n]:y
Step 6 Configure the attributes of the MG interface.
Pay attention to the following when configuring the attributes of the MG interface according to
the data plan:
l The MG interface is registered by the IP address (default mode) or domain name, which must
be the same as that on the MGC.
l The negotiated H.248 protocol version is V1, V2 or V3 (default value). The interface may
fail to be registered because some softswitches do not support V3.
huawei(config-if-h248-0)#if-h248 attribute mgip 10.10.10.10 mgport
2944 code text transfer udp primary-mgc-ip1 200.200.200.200 primary-mgc-port
2944 mg-media-ip1 10.10.10.10 start-negotiate-version 1
Step 7 Reset the MG interface.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
871
