Function description
Chapter 3 OPERATION MANUAL
V1.3.0en/06.07.15//14.06 Liability for errors and misprints excluded. CC®
Description
Standard value
Unit Control Data
without OT
Your setting
- Internal TN 100
- Internal TV 0
- Cascade jacket control KP 200
- Cascade process control KP 4.31
- Cascade process control TN 231.7
- Cascade process control TV -13.46
(Service function for switching
from RidR to standard struc-
ture)
Off
Safety function
- Upper alarm threshold,
internal
Max. working
temperature + 20 K
- Lower alarm limit, internal
Min. working
temperature – 20 K
- Upper alarm threshold,
process
Max. working
temperature + 20 K
- Lower alarm threshold,
process
Min. working
temperature – 20 K
- Hydrostatic correction 1,000 mbar
- Warning time limit (CC-E
only)
30 min
- Min. level (for devices with
analogue level sensor)
0 %
- Max. level (for devices with
analogue level sensor)
100 %
- Freeze protection Off
Setpoint 20 °C
Setpoint limiting
- Minimum Setpoint 5 °C
- Max. setpoint 35 °C
Language Undefined
Temperature format °C
Temperature control mode Internal
Favourites menu
No user menus avail-
able
Pilot ONE Ethernet
- IP address 0.0.0.0
- Subnet mask 255.255.255.0
- Remote Access Deactivated
Time format Minutes
2. Setpoint 5 °C
