Chapter 3 • Installing the HN7000S remote terminal
1037076-0001 Revision C
9
Chapter 3
Installing the HN7000S remote terminal
This chapter explains how to install an HN7000S remote terminal
and register it for service.
The following topics are discussed:
• Attaching the remote terminal to the pedestal base on page 9
• Using the Activation Software CD on page 11
• Disabling web browser proxy settings on page 13
• Configuring your computer’s TCP/IP settings on page 15
• Connecting component cables on page 26
• Completing the activation process on page 27 2
• Testing the connection between the computer and remote
terminal on page 36
• Registering the remote terminal for service on page 39
Attaching the remote
terminal to the pedestal
base
Refer to Figure 4 and follow the steps below to attach the remote
terminal to the pedestal base.
1. Remove the DW6000/DW7000 from the pedestal base by
gently pulling up and back on the tab on the bottom rear of
the base, as shown in
Figure 4. You can then slide the base off
the remote terminal.
Note: Although use of the pedestal base is optional for
Enterprise customers, Hughes strongly recommends that you use it
whenever possible. The pedestal base ensures that the remote
terminal receives proper ventilation. If you do not use the pedestal
base, you must make sure that the ventilation openings on the unit
are not blocked during operation. If you are not planning to attach
the unit to a pedestal base, skip to
Connecting component cables
on page 26.
