Version 24DM
Diagrams, exploded views and replacement parts 6-- 59
SPARE PARTS
Code Description U.of M. Quantity
001.3111 STOP SPACER NR 1,000
001.4701 FIXED PLATFORM NR 1,000
001.4702 TURNT ABLE NR 1,000
002.0101 FIXED LEFT VICE JAW NR 1,000
002.0102 FIXED RIGHT VICE JAW NR 1,000
007.3819 CENTRE PIN NR 1,000
007.3827 BUSHING FOR STOP NR 1,000
007.3895 BUSH 0 38 FOR ROLLER NR 2,000
007.3900 CUT TO MEASURE ROD NR 1,000
007.4021 TURNT ABLE LOCKING PIN NR 1,000
007.4536 FIXED POINT PIN NR 1,000
007.4601 FIXED POINT PIN NR 1,000
007.4611 STOP FOR 60› RIGHT--LEFT SH200 NR 1,000
010.0352 SELF--LOCKING RING NUT 35X1,5 NR 1,000
010.0370 RING NUT 5S 30X1,5 NR 1,000
010.0451 CUT TO MEASURE STOP TIE ROD NR 1,000
010.0805 D38/15 T.15.05 CARBONITRIDED ROLLER NR 1,000
010.0902 FIXED POINT HEAD SPRINGS NR 1,000
010.1204 M 6 LUBRICATOR NR 2,000
010.1464 SPRING BRACKET COUPLER NR 1,000
010.1656 PIN TO SPRING SLEEVE NR 1,000
010.3148 STOP SUPPORT NR 1,000
010.7009 030SNAPRING NR 1,000
010.7204 M8 SCREW NUT NR 5,000
010.7206 M12 SCREW NUT NR 1,000
010.7208 M16 SCREW NUT NR 2,000
010.7480 8 X 30 LEVEL POINT VCE GRUB SCREW NR 2,000
010.7481 8 X 35 LEVEL POINT VCE GRUB SCREW NR 2,000
010.7491 10 X 60 LEVEL POINT VCE GRUB SCREW NR 1,000
010.7604 0 8 WASHER NR 2,000
010.7605 0 10 WASHER NR 6,000
010.7607 0 16 WASHER NR 2,000
010.7759 ELASTIC PIN DIA M. 3 X 16 NR 1,000
010.7761 ELASTIC PIN DIA M. 4 X 20 NR 1,000
010.7870 TCEI 6 X 16 SCREW NR 1,000
010.7876 TCEI 6 X 45 SCREW NR 2,000
010.7894 TCEI 8 X 25 SCREW NR 2,000
010.7940 TCEI 12 X 30 SCREW NR 2,000
010.7942 TCEI 12 X 40 SCREW NR 2,000
010.7964 TE 8 X 30 SCREW NR 1,000
010.7965 TE 8 X 35 SCREW NR 1,000
010.7969 TE 8 X 50 SCREW NR 1,000
010.7975 TE 10 X 25 SCREW NR 4,000
010.7976 TE 10 X 30 SCREW NR 2,000
010.7988 TE 12 X 60 SCREW NR 1,000
016.1038 BAR SUPPORT ARM NR 1,000
025.0080 AXIAL CAGE WITH ROLLERS AXK 3552 NR 1,000
025.0082 FIFTH WHEEL AS 3552 NR 2,000
025.0245 O RING 3275--69,52 NR 1,000
025.0452 ROLLERS 6X6 AISI 420 NR 139,000
034.0398 HEAD PIVOT COVER NR 1,000
034.1001 8 MA PK55 RATCHET LEVER NR 1,000
034.1002 10 MA RATCHET LEVER NR 1,000
034.1203 NS. HANDGRIP M10 DESIGN NR 1,000
