Version 24DM
Maintenance and choice of consumables 8--3
Maintenance of operating parts
In maintenance work on the DM 8 G, special attention should be paid to
operating units such as the blade tensioning cylinder, already dealt with in
Chapter 7, topping up levels, the air treatment unit, the pneumatic vice on the
MA version, and the CUT CONTROL SYSTEM. The transmission box equip-
ping the machine needs no maintenance.
Consumables
Only specified oils must be used for the hydraulic and pneumatic and for
lubricant/coolant devices. Below is a list of compatible oils for each of these
circuits.
Oil for blade tensioner cylinder
The type of oil supplied with the machine is AGIP OSO 15, class F, ISO and UNI
FD22;Thefollowingarecompatibleorequivalentoils:
API Cis 22 --- ARAL Dural SR 22 --- CASTROL Hyspin AWS 22
ESSO Spinesso 22 --- IP Hydrus oil 22 --- TOTAL Azolla ZS 22
VA LV O L I N E E T C 2 2 --- M O B I L Ve l o c i t e o i l D --- M o b i l D T E 2 2
M O B I L AT F 2 2 0 --- O L I O F I AT H T F 2 2 --- Q 8 H a y d n 2 2
SHELL Tellus oil 22 BP AUTRAN GM---MP;
Blade tensioner unit:
--- tank capacity Litres 0.6
--- oil volume Litres 0.5
Oils fo r Cut Co n t rol System hydraulic circuit
The type of oil supplied with the machine is MOBIL DTE 11, ISO and UNI FD
22; it is used in the cylinder head of the Cut Control System. The compatible oils
are those listed in the blade tensioner unit oils above.
Cut Control System:
--- tank capacity Littres 0.2
Oil for transmission box
The machine is equipped with a worm gear which is permanently lubricated and
therefore maintenance---free. The box has no filler cap, level checker and drain,
as it already contains the correct quantity of synthetic oil, guaranteeing perpetual
lubrication of the crown and worm gear. Below is a short list of synthetic oils for
permanent lubrication:
BP Energol SG XP220 --- KLUBER Syntheso D220EP
ESSO Glycolube Rang e 220 --- IP CT614 --- SHELL Tivela Oil SC 320
FINA Girans.
--- transmission box capacity Litres 0.320
