Version 24DM
Diagrams, exploded views and replacement parts 6-- 61
SPARE PARTS
Code Description U.of M. Quantity
007.4209 CYLINDER EXTENSION NR 1,000
010.0914 HEAD RETURNING ACTION SPRING NR 1,000
010.1103 16 X 1,5 RATCHET FORK NR 1,000
010.1463 CYLINDER SUPPORT BRACKET NR 1,000
010.1464 SPRING BRACKET COUPLER NR 1,000
010.1502 CUT CONTROL FIX BRACKET NR 1,000
010.1656 PIN TO SPRING SLEEVE NR 1,000
010.7203 M6 SCREW NUT NR 2,000
010.7605 0 10 WASHER NR 2,000
010.7661 WASHER THICKNESS DIA M. 6 X 3 NR 2,000
010.7830 5 X 10 BUTTON SCREW NR 6,000
010.7860 TCEI 5 X 15 SCREW NR 2,000
010.7870 TCEI 6 X 16 SCREW NR 2,000
010.7871 TCEI 6 X 20 SCREW NR 2,000
010.7923 TCEI 10 X 25 SCREW NR 2,000
010.7976 TE 10 X 30 SCREW NR 2,000
016.0296 EXTERNAL CYLINDER BRACKET NR 1,000
016.1210 HEAD DESCENT REGULATOR FI X HOUSING NR 5,000
022.0235 FLEXIBLE CABLE PRESSER 3243 BLACK PG 11 NR 2,000
022.0245 LOCK NUT 3213B GREY PG 11 NR 2,000
022.0506 HEAD STROKE STOP D4C--1901 2M FEEDER NR 1,000
025.0070 BEARING 51103 NR 1,000
031.3303 HEAD DESCENT ADJUSTMENT ALUMINIUM NAME PLATE NR 1,000
034.1115 SCT SPRING ADJUSTMENT HANDWHEEL NR 1,000
043.0045 HEAD DESCENT REGULATOR CYLINDER NR 2,000
