MEP S.p.A.
5--12 Use and maintenance manual DM 8
" Pull the eccentric pin knob towards you (0˚ reference stop) and rotate slightly
to raise it.
The 0, 45 and 60˚ reference stops for cuts to the left and the 45˚ reference
stop for cuts to the right facilitate rapid head positioning during turntable rota-
tion. However, the eccentric pin is only correctly positioned if the initial rotation
of the turntable when released is corrected.
" Swing the head from left to right until it is positioned at the required angle, as
indicated by the graduated scale on the turntable.
Always rotate with the head raised, so that there is no risk of collision between
the blade and the fixed vice jaws.
" Relock the turntable lock/release lever.
" Make the cut in the required operating mode, following the preliminary
safety instructions set out in this chapter.
Warning
Attention
