Version 24DM
Diagrams, exploded views and replacement parts 6-- 43
SPARE PARTS
Code Description U.of M. Quantity
001.4018 BLADE TENSIONER SLIDE NR 1,000
001.4208 HEAD GUIDE LOCKING BRACKET NR 1,000
001.4255 IDLER PULLEY NR 1,000
001.4260 IDLER PULLEY SECTION BOW NR 1,000
007.3811 HANDWHEEL SPACER NR 1,000
007.3825 BLADE TENSIONING REGULATING PIN NR 1,000
007.3843 FREE FLYWHEEL SHAFT NR 1,000
007.3861 TENSIONING CYCLINDER NR 1,000
007.3869 BLADE TENSIONING PISTON NR 1,000
007.3884 GIB SLIDE BLADE TIGHTENER NR 2,000
007.4002 FRONT BLADE GUIDE HEAD BRACKET NR 1,000
010.0352 SELF--LOCKING RING NUT 35X1,5 NR 1,000
010.0915 BELLEVILLE W ASHER 50X18,4X3 NR 6,000
010.1712 FRONT INSERT BLADE GUIDE NR 1,000
010.1714 FRONT INSERTS BLADE GUIDE NR 1,000
010.1721 BLADE PUSHER NR 1,000
010.1909 BT/NOT--AUS HEAD COMMAND LEVER NR 1,000
010.2381 FRONT BLADE GUIDE HEAD NR 1,000
010.7203 M6 SCREW NUT NR 6,000
010.7402 6 X 12 CYLINDRICAL POINT VCE GRUB SCREW NR 5,000
010.7410 8 X 16 CYLINDRICAL POINT VCE GRUB SCREW NR 1,000
010.7456 8 X 16 CONICAL POINT VCE GRUB SCREW NR 1,000
010.7461 6 X 25 LEVEL POINT VCE GRUB SCREW NR 6,000
010.7491 10 X 60 LEVEL POINT VCE GRUB SCREW NR 1,000
010.7603 0 6 WASHER NR 7,000
010.7606 0 12 WASHER NR 1,000
010.7764 ELASTIC PIN DIA M. 6 X 20 NR 4,000
010.7767 ELASTIC PIN DIA M. 6 X 35 NR 1,000
010.7868 TCEI 6 X 12 SCREW NR 1,000
010.7890 TCEI 8 X 12 SCREW NR 2,000
010.7893 TCEI 8 X 20 SCREW NR 2,000
010.7894 TCEI 8 X 25 SCREW NR 4,000
010.7942 TCEI 12 X 40 SCREW NR 1,000
010.7943 TCEI 12 X 45 SCREW NR 2,000
016.0261 FRONT BLADE PROTECTION NR 1,000
025.0069 BEARING 32007X NR 2,000
025.0235 GAS RING NI 150 18--25--4,5 NR 2,000
025.0236 GAS RING NI 150 45--55--7 NR 1,000
025.0272 GUARD RING NILOS 32007 NR 2,000
028.0130 FITTING 1/4--9 CL 2601 NR 1,000
028.0151 PLASTICIZED TUBE 07--11 KG 1,000
034.0206 BLADE TENSIONING HANDWHEEL NR 1,000
034.1002 10 MA RATCHET LEVER NR 1,000
043.0142 OIL PRESSURE SWITCH NR 1,000
043.0222 CL 2033 1/4 CROSS OVER CONNECTOR NR 1,000
043.0229 MF 1/4 -- CL 2520 REDUCTOR NR 1,000
043.0260 TTE41/4--CL2611CAP NR 1,000
043.0275 A2--1/4 -- CL 2500 CONICAL NIPPLE NR 1,000
043.0350 GFV 1/4 GASKET NR 2,000
043.0556 MANOMETER X BLADE TENSIONING NR 1,000
043.0652 1/4F.M.TAP * NR 1,000
090.0271 MEP TYPE COMPLETE HANDGRIP NR 1,000
