Version 24DM
Diagrams, exploded views and replacement parts 6-- 45
SPARE PARTS
Code Description U.of M. Quantity
001.4258 DRIVING PULLEY SECTION BOW NR 1,000
007.3812 HEAD PIVOT BEARING SPACER NR 1,000
007.3813 BOW SPACER NR 1,000
007.3822 HEAD PIVOT SUPPORT PIN NR 1,000
007.4005 60› REAR BLADE GUI DE HEAD BRACKET NR 1,000
007.4057 LIMIT STOP BUSHING NR 1,000
010.0356 SELF--LOCKING RING NUT 45X1,5 NR 1,000
010.0934 SPRING FOR BLADE CLEANER NR 1,000
010.1711 REAR INSERT BLADE GUIDE NR 1,000
010.1713 REAR INSERTS BLADE GUIDE NR 1,000
010.1721 BLADE PUSHER NR 1,000
010.1801 ”SH GALVANISED ””D”” CLOSURE LEVER” NR 1,000
010.2208 BLADE CLEANER BRUSH HOLDER NR 1,000
010.2304 REFRIGERATING LIQUID DISTRIBUTOR NR 1,000
010.2383 REAR BLADE GUIDE HEAD NR 1,000
010.3155 BLADE CLEANER BRUSH FIX BRACKET NR 1,000
010.7010 0 45 US.010.1201 SNAP RING NR 1,000
010.7205 M10 SCREW NUT NR 1,000
010.7226 M6 SELF--THREADING SCREW NUT NR 2,000
010.7402 6 X 12 CYLINDRICAL POINT VCE GRUB SCREW NR 5,000
010.7601 0 4 WASHER NR 1,000
010.7603 0 6 WASHER NR 1,000
010.7850 TCEI4X8SCREW NR 2,000
010.7852 TCEI 4 X 12 SCREW NR 1,000
010.7854 TCEI 4 X 25 SCREW NR 2,000
010.7875 TCEI 6 X 40 SCREW NR 1,000
010.7890 TCEI 8 X 12 SCREW NR 2,000
010.7893 TCEI 8 X 20 SCREW NR 2,000
010.7927 TCEI 10 X 60 SCREW NR 1,000
010.7993 TSPEI 5 X 12 SCREW NR 2,000
016.0248 STRIP PROTECTION NR 1,000
016.0249 REAR BLADE PROTECTION NR 1,000
016.1223 BOW SAFETY SW ITCH FIX PLATE NR 1,000
022.0037 FR 690 SH SAFETY SWITCH NR 1,000
022.0211 QUICK FITTING SEM PG 13,5 NR 1,000
022.0234 FLEXIBLE CABLE PRESSER 3246 BLACK PG 13, NR 1,000
025.0075 BEARING 32009X NR 2,000
025.0225 GAS RING OR 171--68,26 NR 1,000
025.0238 GAS RING OR 149--44,45X3,53 NR 1,000
025.0275 GUARD RING NILOS 32009X NR 2,000
025.0552 BLADE CLEANER BRUSH 6X25 030 NR 1,000
025.0803 GRAPHITIZ ED BUSH L. 10 DIA M. 6 NR 2,000
028.0121 FITTING 3/8--17 CL 2601 NR 1,000
028.0130 FITTING 1/4--9 CL 2601 NR 3,000
028.0360 BLADE CLEANER RUBBER NR 1,000
034.0801 P 40/30 ELASTIC STOP NR 1,000
043.0229 MF 1/4 -- CL 2520 REDUCTOR NR 1,000
043.0652 1/4F.M.TAP * NR 1,000
