Diagrams, exploded views and replacement parts 6-- 49
SPARE PARTS
Code Description U.of M. Quantity
001.4007 SLIDING VICE NR 1,000
001.4037 VICE SUPPORT NR 1,000
007.3824 QUICK CLAMPING VICE LOCKING PIN NR 1,000
007.3839 VICE GIB NR 1,000
007.3891 VICE SCREW BUSHING NR 1,000
007.4058 CAM BUSHING NR 1,000
007.4081 UNLOCKING LOWER VICE PINION NR 1,000
010.0211 525X24TPN VICE SCREW NR 1,000
010.0540 MOBILE VICE JAW NR 1,000
010.0918 LEAD SCREW VICE RETURNING ACTION SPRING NR 1,000
010.1202 SPHERICAL DIA M. 8 OILER NR 3,000
010.2372 45› BRONZE LEAD SCREW NR 1,000
010.7203 M6 SCREW NUT NR 7,000
010.7456 8 X 16 CONICAL POINT VCE GRUB SCREW NR 5,000
010.7463 6 X 35 CONICAL POINT VCE GRUB SCREW NR 7,000
010.7491 10 X 60 LEVEL POINT VCE GRUB SCREW NR 1,000
010.7603 0 6 WASHER NR 7,000
010.7767 ELASTIC PIN DIA M. 6 X 35 NR 1,000
010.7894 TCEI 8 X 25 SCREW NR 2,000
034.0205 VPRA/125 MR HANDWHEEL NR 1,000
034.1002 10 MA RATCHET LEVER NR 1,000
034.1003 12 MA RATCHET LEVER NR 1,000
