Assemblies and Parts Lists: 8-30
Frame Assembly Parts List
Item Part Number Description Qty
1 610-021-749 ASSEMBLY, BACK PRESSURE SWITCH MOUNT 1
2 610-021-009 ASSEMBLY, IDLER PULLEY 1
3 610-026-747 ASSEMBLY, SOLENOID VALVE - CTS 403 FLEX 1
4 000-015-1304 BRACKET, HOSE TIE DOWN 1
5 000-027-110 CAP, 2” X 3” FRAME END 2
6 000-033-057 CLAMP, 1” CUSHION LOOP 2
7 000-033-050 CLAMP, 1-3/4” CUSHION LOOP 2
8 000-033-046 CLAMP, 1/2” WIDE X 1/2” TUBE 1
9 000-033-067 CLAMP, 2” CUSHION LOOP 1
10 000-033-134 CLAMP, 3/4 ID, CUSHION 2
11 000-033-128 CLAMP, 3/8” NYLON HOSE 1
12 000-055-195 FRAME, COMPLETE - COATED 1
13 000-143-583 SCREW, #10-24UNC x 0.50” LG. HEX H FLANGE Z/P 9
14 000-143-065 SCREW, #10-24UNC x 1.75” LG. HEX HEAD 1
15 000-174-001 WASHER, #10 FLAT 1
Item Part Number Description Qty
