8-25: Assemblies and Parts Lists
Exhaust Diverted Assembly Parts List
1 000-033-068 CLAMP, 1-1/2” EXHAUST 2
2 000-041-043 COVER, DIVERTER EXHAUST 1
3 000-105-181 FLANGE, Ø1.50” EXHAUST DONUT - COATED 1
4 000-057-199 GASKET, EXHAUST DONUT 1
5 000-057-146 GASKET, FOUR HOLE EXHAUST 2
6 000-094-016 NUT, 3/8”-16UNC HEX WHIZ LOCK 2
7 000-094-081 NUT, 5/16”-18UNC HEX 2 WAY LOCKING 2
8 000-094-078 NUT, 5/16”-18UNC HEX FLANGE 4
9 000-143-758 SCREW, 1/4-20 X 1/2” GD8 ZINC HHC 4
Item Part Number Description Qty
10 000-143-124 SCREW, 5/16”-18UNC x 1.75” LG. HEX HEAD 2
11 000-143-572 SCREW, 5/16”-18UNC x 5/8” LG. GRD. 5 HEX HEAD 4
12 000-125-199 TUBE, EXHAUST DIVERT - WELDMENT 1
13 000-125-266 TUBE, EXHAUST 4.60” LG. W/ FLARE 1
14 000-125-940 TUBE, EXHAUST DIVERT - WELDMENT 1
15 000-174-049 WASHER, 5/16” FLAT 4
16 000-174-209 WASHER, 1/4” TAB PLENUM BOX 2
17 000-174-208 WASHER, 5/16” TAB DIVERTER BOX 2
Item Part Number Description Qty
