8-21: Assemblies and Parts Lists
Engine Assembly Parts List
1 000-020-025 BUSHING, H X 1” 1
2 000-033-117 CLAMP, 1” CUSHION LOOP w/ 7/16 MOUNT HOLE 2
3 000-039-060 COUPLER, GUARDIAN 7/8” X 1” BORE - 18/23 HP 1
4 000-047-037 ENGINE, B&S 23HP 1
5 000-057-026 GASKET, 1/2” X 1/4” X 18-1/8” LG. 2
6 000-057-226 GASKET, ENGINE DUCT 2
7 000-068-979 HOSE, 1/4” I.D. FUEL LOW PERM x 120” LG. 1
8 000-068-1006 HOSE, 5/32” I.D. RUBBER/VACUUM X 1.5” LG. 4
9 000-068-1007 HOSE, 5/32” RUBBER VAC X 4.5” LG 1
10 000-068-219 HOSE, DRAIN 1
11 000-042-074 HOUSING, RADIATOR DUCT - COATED 1
12 000-052-293 INSERT, #23 (1/8” NPT x 3/16” BARB) 1
13 000-131-139 INSULATION, 1” HI-TEMP ALUM SLEEVE x 60” LG. 1
14 000-077-010 KEY, 1/4” x 1-1/2” LG. CLASS 2 FIT 2
15 000-094-081 NUT, 5/16”-18UNC HEX 2 WAY LOCKING 4
16 000-094-012 NUT, 5/16”-18UNC HEX 1
17 000-094-125 NUT, 6MM HEX NYLOCK FLANGE S/S 4
18 000-105-562 PLATE, ENGINE DUCT - COATED 1
19 000-109-040 PULLEY, AK47-H 1
20 000-140-001 RIVET, AB4-3A ALUMINUM POP 1/8” x 1/4” LG. 12
21 000-143-126 SCREW, #10-24UNC x 0.50” LG. HEX HEAD 4
22 000-143-659 SCREW, 5/16”-18UNC X 3.5” LG. GRADE 8 2
23 000-143-660 SCREW, 5/16”-18UNC X 4.0” LG., HEX HEAD 2
24 000-150-169 SHAFT, B&S 23HP STUB 1
25 000-052-155 TEE, 3/16” PLASTIC VACUUM INSERT 2
26 000-131-060 TRIMLOK, 3/4” BULB x 3/16” OPENING (40” LG.) 3.33’
27 000-169-156 VALVE, CHECK - DIVERTER CONTROL 2
28 000-174-001 WASHER, #10 FLAT 4
29 000-174-002 WASHER, 1/4” FLAT 6
30 000-174-004 WASHER, 5/16” FLAT, USS 4
Item Part Number Description Qty Item Part Number Description Qty
