Assemblies and Parts Lists: 8-52
Figure 8-42. 35 Gallon Tank Flex Chemical Caddy Assembly
000-163-757 Rev. B
35 Gallon Tank Flex Chemical Caddy Assembly Parts List
1 000-015-1265 Bracket, Tank Stiener 4
2 000-015-1264 Bracket, Tank Tray Rib 3
3 000-094-071 Nut, 1/4”-20UNC Nylock Half 12
4 000-143-333 Screw, 1/4”-20UNC X 0.50” Lg. Hex Head 12
5 000-166-179 Tray, Tank - 26” 1
6 000-174-003 Washer, 1/4” Flat 12
Item Part Number Description Qty
