2-7: Operating Instructions
FLEX TANK OPERATION
1. Make sure the 3-way ball valve levers are all in the downward or vertical position
(see Figure 2-5). The levers on the Flex pumps control the direction of the chemical
ow. When the levers are in the vertical position, the ow is turned “OFF”.
2. Open the Flex solution tank lid(s) and ll the solution tank(s) with appropriate
ChemDry solution until the solution levels o below the tank vent hose hole.
Figure 2-5. Flex Pump Levers
3-WAY BALL
VALVES
LEVER
LEVER
Figure 2-6. For 50 Gallon/Tank Assembly:
Turn Lever to Tank Drain Hose or in Direction of Pump Strainer
To Tank To Tank
Drain HoseDrain Hose
To Pump To Pump
StrainerStrainer
LEVER
50 GALLON 50 GALLON
TANKTANK
