HydraMaster CTS 403 Flex - Silencer Assembly Parts List

Assemblies and Parts Lists: 8-40
Silencer Assembly Parts List
1 000-033-011 Clamp, Size #36 Hose 4
2 000-068-984 Hose, 2.5” Heat Flex NS X 1.5” Lg. 1
3 000-068-985 Hose, 2.5” Heat Flex NS X 12” Lg. 1
4 000-108-036 Protector, Silencer 1
5 000-143-583 Screw, #10-24UNC X 0.50” Lg. Hex Head Flange Z/P 4
6 000-093-022 Silencer, 2.5” Cowl 1
Item Part Number Description Qty
Figure 8-32. Silencer Assembly
610-021-728 Rev. A
1
3
4
2
15
4X
6
