HydraMaster CTS 403 Flex - Dash Assembly Parts List

Assemblies and Parts Lists: 8-18
Dash Assembly Parts List
1 000-052-804 ADAPTER, S.S. JET X 1/4” FNPT 1
2 000-001-148 ADAPTER, 2.5” EXHAUST TURNDOWN - COATED 1
3 000-025-003 CABLE, CHOKE WITH DETENT 1
4 000-025-032 CABLE, THROTTLE - MODIFIED 403 1
5 000-052-272 CUP, GRAVITY FEED OIL BLOWER LUBE PORT 1
6 000-052-088 ELBOW, 1/4” FPT x FPT 1
7 000-049-253 FILTER CARTRIDGE, 1/4” SS 1
8 000-074-007 GAUGE, PRESSURE 0 -1500 PSI, UPC #401406. 1
9 000-074-017 GAUGE, 30” HG. VACUUM - HYDRAMASTER 1
10 000-052-803 HOUSING, 1/4” S.S. FILTER 1
11 000-052-104 INSERT, #66 (3/8” NPT x 3/8” BARB) 1
12 000-052-105 INSERT, #68 (3/8” NPT x 1/2” BARB) 2
13 000-052-096 INSERT, #F23 (1/8” FPT x 3/16” BARB) 1
14 000-081-555 LABEL SET - CTS 403 FLEX 1
15 000-131-131 LABEL, DOME - 403 1
16 000-084-011 LIGHT, RED LED INDICATOR MINI 1
17 000-074-170 METER, RECTANGULAR HOUR w/o BEZEL 1
18 000-052-526 NIPPLE, 1/4” NPT x 1/4” JIC 1
19 000-052-095 NIPPLE, 1/4” S/S HEX 1
20 000-052-527 NIPPLE, 1/4” SAE x 1/4” NPT 1
21 000-052-533 NIPPLE, 3/8” JIC x 1/4” NPT 1
22 000-094-009 NUT, 1/4”-20UNC NYLOCK 4
23 000-180-031 ORIFICE, PLATE 0.052” 1
Item Part Number Description Qty Item Part Number Description Qty
24 000-100-391 PANEL, DASH - COATED E01 1
25 000-100-390 PANEL, GRILL - TITAN 325/425 1
26 000-052-690 QUICK CONNECT, 1/4” FEMALE S/S 1
27 000-052-051 QUICK CONNECT, 440 FEMALE w/ EPDM O-RING 1
28 000-052-052 QUICK CONNECT, 660 3/8” BRASS W/ EPDM O-RING 1
29 000-135-052 REGULATOR, HI PSI SNUBBER 1
30 000-143-126 SCREW, #10-24UNC x 0.50” LG. HEX HEAD 8
31 000-143-171 SCREW, #10-24UNC x 1.25” LG. HEX HEAD 4
32 000-157-060 SWITCH, ROTARY, 4 POSITION 1
33 000-157-040 SWITCH, 20 AMP ROCKER 2
34 000-157-017 SWITCH, IGNITION - B & S 1
35 000-052-189 TEE, 1/4” FEMALE SS 1
36 000-149-025 THERMOSTAT, BULB & CAPILLARY 1
37 000-131-131 TRIMLOK, 3/8” x 1/8” RUBBER 3.33’
38 000-169-064 VALVE, 3/8” NPT FULL PORT BALL 1
39 000-169-243 VALVE, 3000 PSI POP OFF 1
40 000-174-001 WASHER, #10 FLAT 12
41 000-174-007 WASHER, 1/2” FLAT 2
42 000-174-003 WASHER, 1/4” FLAT S/S 4
43 000-174-058 WASHER, 21/32” I.D. x 27/32” O.D. NYLON 1
44 000-174-032 WASHER, 3/8” FLAT 2
45 000-174-008 WASHER, 5/8” FLAT 4
