HydraMaster CTS 403 Flex - Dump Hose Hook up Kit

8-49: Assemblies and Parts Lists
Figure 8-39. Dump Hose Hook Up Kit
000-078-957 Rev. A
1
2
1
3
3
LTR REVISION DESCRIPTION CODE DATE BY CHKD APPVD
A RELEASED DRAWING.
ECR #2806
12/01/2017 P.E. R.D.D. ECRB
ITEM
NO.
QTY. DESCRIPTION MATERIAL PART NO.
3 2 INSERT, 1-1/2" NPT x 1-1/2" BARB (GREY) PVC 000-052-226
2 1 HOSE, 1.5" I.D. RED STRIPE X 48" LG. VARIOUS 000-068-882
1 2 CLAMP, 2" T-BOLT S. STEEL 000-033-063
D
C
B
A
B
C
D
1
2
3
4
8
7
6
5
4
3
2
1
DRAWN
CHECKED
APPVD
SCALE: 1:8
SHEET 1 OF 1
8
7
6
5
A
PROPRIETARY INFORMATION
11015 47th Avenue West,
Mukilteo, Washington 98275
B
SIZE
TOLERANCES
.X= .1
.XX= .03
.XXX= .010
ANGULAR = 2°
BREAK ALL SHARP EDGES 0.005-.015
UNLESS OTHERWISE NOTED
DIMENSIONS ARE IN INCHES
PART NUMBER
WEIGHT:
APPLICATION
NEXT ASSY USED ON
P.E. 11/28/2017
11/28/2017
11/28/2017
REV
A
KIT - DUMP HOSE HOOK UP
MACHINE
FINISH
125
R.D.D.
R.D.D.
CTS 400
PRJ000245
000-078-614
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
000-078-957
CODE:
1.90
Dump Hose Hook Up Kit Parts List
Item Part Number Description Qty
1 000-033-063 CLAMP, 2” T-BOLT 2
2 000-068-882 HOSE, 1.5” I.D. RED STRIPE X 48” LG. 1
3 000-052-226 INSERT, 1-1/2” NPT x 1-1/2” BARB (GREY) 2
