HydraMaster CTS 403 Flex - Page 121

Assemblies and Parts Lists: 8-50
Figure 8-40. Sacricial Anode Assembly
610-029-724 Rev. B
B
A
DETAIL B
SCALE 2 : 2.5
3
9
10
4
10
7
DETAIL A
SCALE 2 : 2.5
8
6
1
6
8
5
5
7
3
2
10
4
10
C
B
B
B
LTR REVISION DESCRIPTION CODE DATE BY CHKD APPVD
B
000-108-025 WAS 000-108-022; 000-094-034 WAS
000-094-058; 000-094-150 WAS 000-094-027. FIXED
000-025-098 BOM DESC.
-
9/18/2019 T.D.L. P.E. P.E.
C 000-025-098 31.0" WAS 36.0"
-
12/17/2019 P.T. P.E. P.E.
ITEM NO. QTY. DESCRIPTION MATERIAL PART NO.
10 4 WASHER, #10 FLAT S. STEEL 000-174-001
9 1 WASHER, #10 EXTERNAL STAR STEEL 000-174-015
8 2 SCREW, #10-24UNC x 1.25" LG. HEX HEAD S. STEEL 000-143-171
7 2 SCREW, #10-24UNC x 0.75" LG. HEX HEAD S. STEEL 000-143-132
6 2 PROTECTOR, MAGNESIUM ANODE - UNMODIFIED MAGNESIUM 000-108-025
5 2 NUT, 10-24 S/S NYLOK HALF S. STEEL 000-094-150
4 2 NUT, #10-24UNC HEX NYLOCK S. STEEL 000-094-034
3 2 CLAMP, WIRE SLEEVE 1/16Ø S-STEEL S. STEEL 000-033-149
2 1 CABLE, 1/16 S-STEEL - 31" S. STEEL 000-025-098
1 1 BRACKET, SACRIFICIAL ANODE - FABRICATED 5052-H32 000-015-1413
APPLICATION
- - - - - -
- - - - - -
- - - - - -
- - - - - -
- - - - - -
- - - - - -
- - - - - -
- - - - - -
- - - - - -
- - - - - -
- - - - - -
610-003-801 CDS 4.8
NEXT ASSY USED ON
D
C
B
A
B
C
D
1 2 3
4 5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
A
SACRIFICIAL ANODE, MAGNISIUM
C
REV
000-079-226
12/17/2019
12/17/2019
8/21/2019
USED ON NEXT ASSY
APPLICATION WEIGHT:
PART NUMBER
UNLESS OTHERWISE NOTED
DIMENSIONS ARE IN INCHES
BREAK ALL SHARP EDGES 0.005-.015
SIZE
C
11015 47th Avenue West,
Mukilteo, Washington 98275
PROPRIETARY INFORMATION
SHEET 1 OF 1
SCALE: 1:8
APPVD
CHECKED
DRAWN
125
MACHINE
FINISH
T.D.L.
P.E.
P.E.
70G URT
70G URT 610-003-741
610-003-728
100G URT 610-003-763
100G URT 610-003-423
610-003-080
100G URT
TOLERANCES
.X= .1
.XX= .03
.XXX= .010
ANGULAR = 2°
CODE: 0.205
Sacricial Anode Assembly Parts List
Item Part Number Description Qty
1 000-015-1413 BRACKET, SACRIFICIAL ANODE - FABRICATED 1
2 000-025-098 CABLE, 1/16 S-STEEL - 31” 1
3 000-033-149 CLAMP, WIRE SLEEVE 1/16Ø S-STEEL 2
4 000-094-034 NUT, #10-24UNC HEX NYLOCK 2
5 000-094-150 NUT, 10-24 S/S NYLOK HALF 2
6 000-108-025 PROTECTOR, MAGNESIUM ANODE - UNMODIFIED 2
7 000-143-132 SCREW, #10-24UNC x 0.75” LG. HEX HEAD 2
8 000-143-171 SCREW, #10-24UNC x 1.25” LG. HEX HEAD 2
9 000-174-015 WASHER, #10 EXTERNAL STAR 1
10 000-174-001 WASHER, #10 FLAT 4
