HydraMaster CTS 403 Flex - Gallon and 15 Gallon Tank Flex Kit Assembly Parts List

8-51: Assemblies and Parts Lists
Figure 8-41. 35 Gallon and 15 Gallon Tank Flex Kit Assembly
000-163-753 Rev. D
2
3
1
4
D
ITEM NO. QTY. DESCRIPTION MATERIAL PART NO.
4 2 PROTECTOR, BULKHEAD AISI 304 2B 000-108-196
3 1 FRAME, 12" X 53" TANK - COATED STEEL 000-055-217
2 1 ASSEMBLY, TANK - 35 GAL & 15 GAL VARIOUS 000-163-752
1 1 ASSEMBLY, CHEMICAL CADDY 35 GAL VARIOUS 000-163-757
LTR REVISION DESCRIPTION CODE DATE BY CHKD APPVD
C
UPDATED VIEWS TO CONFORM TO OTHER HRI
FLEX TANK DWGS.
LRIP
11/6/2014 S.M.W. C.I.R. C.I.R.
D 000-163-752 WAS MODIFIED.
NA
2/10/2020 P.E. M.B.B. M.B.B.
D
C
B
A
B
C
D
1 2 3
4 5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
A
ASSEMBLY, TANK - 35 GAL & 15 GAL HRI FLEX KIT
D
REV
000-163-753
11/06/2014
09/29/2014
9/26/2014
USED ON NEXT ASSY
APPLICATION WEIGHT:
PART NUMBER
UNLESS OTHERWISE NOTED
DIMENSIONS ARE IN INCHES
BREAK ALL SHARP EDGES 0.005-.015
SIZE
C
11015 47th Avenue West,
Mukilteo, Washington 98275
PROPRIETARY INFORMATION
SHEET 1 OF 1
SCALE: 1:10
APPVD
CHECKED
DRAWN
125
MACHINE
FINISH
S.M.W.
C.I.R.
C.I.R.
CTS 403 FLEX
- - -- - -
750-010-758
- - -- - -
- - -- - -
- - - - - -
TOLERANCES
.X= .1
.XX= .03
.XXX= .010
ANGULAR = 2°
CODE: 108.77
1 000-163-757 Assembly, Chemical Caddy 35 Gallon 1
2 000-163-752 Assembly, Tank - 35 Gallon and 15 Gallon 1
3 000-055-217 Frame, 12” X 53” Tank - Coated 1
4 000-108-196 Protector, Bulkhead 2
