HydraMaster CTS 403 Flex - Gallon and 15 Gallon Tank Flex Assembly Parts List

Assemblies and Parts Lists: 8-54
35 Gallon and 15 Gallon Tank Flex Assembly Parts List
1 000-052-923 BULKHEAD 2
2 000-033-057 CLAMP, 1” CUSHION LOOP 5
3 000-033-004 CLAMP, SIZE #6 MINI HOSE 11
4 000-041-005 COVER, 6” ACCESS 2
5 000-052-484 ELBOW, 1/2” NPT X 1/2 HOSE 2
6 000-052-355 ELBOW, 3/8” NPT x 1/2” HOSE 2
7 000-057-257 GASKET - 5.25 IN. COVER LID 1
8 000-057-256 GASKET - 6 IN. COVER LID 2
9 000-068-674 HOSE, 1/2” I.D. CLR X 16” LG. - BRAID 2
10 000-068-676 HOSE, 1/2” I.D. CLR X 36” LG. - BRAID 2
11 000-068-677 HOSE, 1/2” I.D. CLR X 54” LG. BRAID - DRAIN HOSE 1
Item Part Number Description Qty Item Part Number Description Qty
12 000-068-678 HOSE, 1/2” I.D. CLRE X 78” LG. BRAID - VENT HOSE 2
13 000-089-003 MAGNET, TREADMASTER 2
14 000-169-588 MINIATURE 3 WAY PVC BALL VALVE 2
15 000-094-034 NUT, #10-24UNC HEX NYLOCK 2
16 000-041-729 PLATE, TANK COVER 1
17 000-106-173 PLUG, 3/8” NPT ALLEN HEAD 2
18 000-143-739 SCREW, #8-15 X 3/4” LG. PAN HEAD SS 15
19 000-143-126 SCREW, #10-24UNC x 0.50” LG. HEX HEAD 2
20 000-159-257 TANK, 15 GALLON - MODIFIED 1
21 000-159-258 TANK, 35 GALLON - MODIFIED 1
The following items are shipped with the Tank Assembly in a plastic bag, ready to
be used at installation: Item 2, 2X; Item 3, 2X; Item 6, 2X ; Item 12, 2X; Item 17, 2X.
