HydraMaster CTS 403 Flex - Console Assembly Parts List

8-13: Assemblies and Parts Lists
Console Assembly Parts List
Item Part Number Description Qty
1 610-002-747 ASSEMBLY, BLOWER - CTS 403 FLEX 1
2 610-018-749 ASSEMBLY, DASH - CTS 403 FLEX 1
3 610-004-749 ASSEMBLY, ENGINE - CTS 403 FLEX 1
4 610-013-749 ASSEMBLY, EXHAUST - CTS 403 1
5 610-001-749 ASSEMBLY, FRAME - CTS 403 FLEX 1
6 610-005-749 ASSEMBLY, HEAT EXCHANGER - CTS 403 FLEX 1
7 610-021-729 ASSEMBLY, ORIFICE 1
8 610-007-747 ASSEMBLY, PUMP - CTS 403 FLEX 1
9 610-021-728 ASSEMBLY, SILENCER 1
10 610-022-749 ASSEMBLY, TOP COVER - CTS 403 FLEX 1
11 610-010-749 ASSEMBLY, WATER BOX - CTS 403 FLEX 1
12 000-010-124 BELT, 9430HD 1
13 000-033-029 CLAMP, SIZE #12 HOSE 2
14 000-033-005 CLAMP, SIZE #5 HOSE 6
15 000-041-451 COVER, LEFT SIDE - COATED 1
16 000-041-452 COVER, RIGHT SIDE - COATED 1
17 000-068-588 HOSE ASSEMBLY, THROB 52” LG. 1
18 000-068-518 HOSE ASSEMBLY, 3/16” TEFLON X 18.25” LG. (PUMP TO
GAUGE) 1
19 000-068-888 HOSE ASSEMBLY, 3/16” TEFLON X 24” LG. (HX TO ORIFICE
ASSY) 1
20 000-068-203 HOSE ASSEMBLY, 3/16” TEFLON X 34” LG. (ORIFICE ASSY
TO WB) 1
21 000-068-627 HOSE ASSEMBLY, 3/16” TEFLON X 44” LG. (ORIFICE TO
REC TANK) 1
22 000-068-760 “HOSE ASSEMBLY, 3/16”” TEFLON X 71”” LG. (HX TO
CHEMDRY SOL OUT)” 1
Item Part Number Description Qty
23 000-068-724 HOSE ASSEMBLY, 5/16” TEFLON X 18” LG. (HX TO SOL
OUT) 1
24 000-068-967 HOSE, 1/2” I.D. RUBBER x 20” LG. (WB DRAIN) 1
25 000-068-968 HOSE, 1/2” I.D. RUBBER x 56” LG. (PUMP TO WB) 1
26 000-068-969 HOSE, 1/2” I.D. RUBBER x 69” LG. (FRESH WATER IN TO
WB) 1
27 000-068-997 “HOSE, 1/4”” I.D. RUBBER X 60”” LG.
(POP OFF VALVE TO THERMO VALVE TEE) &
(THERMO VALVE TEE TO REC TANK)” 1
28 000-068-1133 HOSE, 1/8” HI-TEMP SILICONE X 40” LG. BLACK VAC 1
29 000-068-1059 HOSE, 3/4” I.D. RUBBER x 56” LG. (PUMP TO WB) 1
30 000-068-348 HOSE, 5/32” I.D. VACUUM X 14” LG. (SOL VAVLE TO AIR
CYLINDER) 1
31 000-068-1009 HOSE, 5/32” I.D. VACUUM X 16” LG. (SOL VAVLE TO AIR
CYLINDER) 1
32 000-068-347 HOSE, 5/32” I.D. VACUUM X 36” LG. (SOL INLET TO ENGINE
TEE) 1
33 000-068-978 HOSE, 5/32” I.D. VACUUM X 52” LG. (BLOWER TO LUBE
PORT) 1
34 000-068-977 HOSE, 5/32” I.D. VACUUM X 82” LG. (BLOWER TO VAC
GAUGE) 1
35 000-105-012 PLATE, MACHINE SERIAL I.D. 1
36 000-140-001 RIVET, AB4-3A ALUMINUM POP 1/8” x 1/4” LG. (GRIP
RANGE 0.126”-0.187”) 2
37 000-143-126 SCREW, #10-24UNC x 0.50” LG. HEX HEAD 9
38 000-174-001 WASHER, #10 FLAT 9
39 000-174-014 WASHER, #10 LOCK 9
