Console Hose Routings
Part No. Description Hose Routing
From to
000-068-977 HOSE, 5/32" I.D. VACUUM X 82" LG. BLOWER VAC GAUGE
000-068-978 HOSE, 5/32" I.D. VACUUM X 52" LG. BLOWER LUBE PORT
000-068-347 HOSE, 5/32" I.D. VACUUM X 36" LG. SOL INLET ENGINE TEE
000-068-1009 HOSE, 5/32" I.D. VACUUM X 16" LG. SOL VAVLE AIR CYLINDER
000-068-348 HOSE, 5/32" I.D. VACUUM X 14" LG. SOL VAVLE IR CYLINDER
000-068-1059 HOSE, 3/4" I.D. RUBBER x 56" LG. PUMP WB
000-068-1133 HOSE, 1/8" HI-TEMP SILICONE X 40" LG. BLACK VACUUM HXER PLENUM BACK PRESSURE SENSOR
000-068-997 HOSE, 1/4" I.D. RUBBER X 60" LG. POP OFF VALVE THERMO VALVE TEE
000-068-969 HOSE, 1/2" I.D. RUBBER x 69" LG. FRESH WATER IN WB
000-068-968 HOSE, 1/2" I.D. RUBBER x 56" LG. PUMP WB
000-068-967 HOSE, 1/2" I.D. RUBBER x 20" LG. WB DRAIN
000-068-724 HOSE ASSEMBLY, 5/16" TEFLON X 18" LG. HX SOL OUT
000-068-760 HOSE ASSEMBLY, 3/16" TEFLON X 71" LG. HX CHEMDRY SOL OUT
000-068-627 HOSE ASSEMBLY, 3/16" TEFLON X 44" LG. ORIFICE REC TANK
000-068-203 HOSE ASSEMBLY, 3/16" TEFLON X 34" LG. ORIFICE ASSY WB
000-068-888 HOSE ASSEMBLY, 3/16" TEFLON X 24" LG. HX ORIFICE ASSY
000-068-518 HOSE ASSEMBLY, 3/16" TEFLON X 18.25" LG. PUMP GAUGE
000-068-588 HOSE ASSEMBLY, THROB 52" LG. HX PUMP
