Operating Instructions: 2-8
There are 2 levers on the 35 Gallon/15 Gallon Tank Assembly, one for each tank (see
Figure 2-5). There is 1 lever located on the 3-way ball valve on the 50 Gallon Tank
Assembly (see Figure 2-6).
Before operating the Flex System, turn the appropriate lever toward the direction of the
ow (toward the hose connected to the pump strainer - see Figure 2-6 and Figure 2-7).
To drain the pumps, turn the lever away from the ow.
To turn the ow o󰀨, turn the levers downward or in the vertical position.
LEVER
15 GALLON 15 GALLON
TANKTANK
35 GALLON
TANK
LEVER
To Pump To Pump
StrainerStrainer
To Tank To Tank
Drain HoseDrain Hose
To Pump To Pump
StrainerStrainer
To Tank To Tank
Drain HoseDrain Hose
Figure 2-7. For 35 Gallon/15 Gallon Tank Assembly:
Turn Levers in Direction of Pump Strainer or to Tank Drain Hose
