Installation
DynaMAX 550P/560P/575P Waterjet Pump Operator Manual 811390 197
Parts, tools, and materials
1. Remove the caps from the fittings and the plugs from the utility connections.
2. Connect the utilities to the pump.
Keep these parts to use if the pump is stored or shipped.
5/8-inch open-ended wrench
13/16-inch open-ended wrench
1-1/2-inch open-ended wrench
Torque wrench
High-pressure antiseize lubricant such as
Blue Goop or PURE Goop
3/8-inch high-pressure male fitting
NPT male fitting
Two 1/2-inch NPT male fittings
Water-cooled system
Two 1-inch NPT male fittings
Refer to Fittings on page 182 for torque values and information about how to correctly install
water fittings.
All low-pressure water connections use push-to-connect fittings.
