Installation
198 811390 Operator Manual DynaMAX 550P/560P/575P Waterjet Pump
CUTTING WATER OUT
This tubing carries high-pressure water from
the intensifier to the cutting table.
• Connect 1 end of the high-pressure tubing
to the cutting head.
• Connect the other end to the fitting on the
pump’s utility panel.
Factory-installed connection: 3/8-inch high-pressure female
C
OMPRESSED AIR
The bleed-down valve uses compressed air to
operate.
Connect the other end to the fitting on the
pump’s utility panel.
Factory-installed fitting: 1/4-inch NPT female
W
ASTE WATE R OUT
This hose carries water from the bleed-down
valve to a drain.
• Connect 1 end of this hose to the drain.
• Connect the other end to the fitting on the
pump’s utility panel.
Factory-installed connection: 1/2-inch NPT female
C
UTTING WATER IN
This line carries low-pressure water from a
water softener, a reverse osmosis system, a
well, or a public utility to the pump.
• Connect 1 end of this line to the supply
water.
• Connect the other end to the fitting on the
pump’s utility panel.
All low-pressure water connections use
push-to-connect fittings.
Factory-installed connection: 1/2-inch NPT female
C
OOLING IN
Water-cooled system
This line carries low-pressure supply water
from the local utility or a chiller to the pump’s
cooling loop.
• Connect 1 end of this line to the supply
water or to the chiller.
• Connect the other end to the fitting on the
pump’s utility panel.
Factory-installed fitting: 1-inch NPT female
Air-cooled system
This hose carries hydraulic fluid from the
external heat exchanger to the hydraulic fluid
tank.
• Connect 1 end of this line to the fitting
marked OUTLET on the external heat
exchanger.
• Connect the other end to the ball valve at
the heat exchanger inlet.
Factory-installed fitting: -16 JIC male
