Specifications
6
136 810770 Operator Manual Echion
Specifications
All Echion-model pumps
Environmental conditions
Hydraulic fluid
A laboratory analysis of hydraulic fluid can tell you if replacement is recommended.
The maximum contamination from particulates that is permitted is19/17/14 when tested according
toISO 4406. The maximum recommended contamination from water is300 ppm when tested
according to ASTM D6304c-04. If it is not practical to analyze a sample of your hydraulic fluid,
Hypertherm recommends replacing it every3,000 hours.
Refer to Replace the hydraulic fluid on page 86.
Glycol can be added to the cooling circuit to prevent freezing, but glycol is less efficient for
cooling than water.
Hypertherm recommends using a solution of not more than25% glycol in chillers for this
system.
Ambient air temperature 4°C to 35°C (40°F to 95°F)
Relative humidity
Noncondensing
95%
Storage temperature
Water not drained
2°C to 55°C (35°F to 131°F)
Domestic pumps ship from the factory with AW 32 hydraulic fluid.
Type Antiwear (AW) mineral oil or synthetic hydraulic fluid, ISO viscosity
grade (VG) 32 or 46
Hydraulic fluid tank capacity 120 L (32 gallons)
Maximum pressure
Set at the factory
217 bar (21,700 kPa / 3,150 psi)
Operation temperature 46°C to 54°C (115°F to 130°F)
