Operation
2
Echion Operator Manual 810770 47
Operation
Check the hydraulic fluid level
Do this task when the pump is operating.
Make sure that the hydraulic fluid level is at the top mark on the sight gauge.
Add hydraulic fluid, if necessary. Refer to Add hydraulic fluid on page 85 for instructions.
Check the hydraulic filter gauge
Do this task when the pump is operating at a stable temperature.
Make sure that the needle on the hydraulic gauge is not in the red zone.
Replace the hydraulic filter element:
• every 1,500 hours.
• when the needle on the gauge stays in the red zone while the pump is operating.
Refer to Replace the hydraulic filter element on page 84.
