d-2 MAX200 Instruction Manual
15
APPENDIX D
Plasma Gas/ Retaining Swirl
Metal Amps Shield Gas Shield Cap Nozzle Ring Electrode Page
Mild 200 Air / Air 020918 020915 020608 020607 220021 4-19
Steel 100 Air / Air 020919 020915 020611 020607 120547 4-20
40 Air / Air 020917 020915 020689 020613 220021 4-21
200 O
2
/ Air 020918 020915 020605 020604 220021 4-22
100 O
2
/ Air 020919 020915 020616 020617 120547 4-23
200 N
2
/ CO
2
020918 020915 020608 020607 020415 4-24
Stainless 200 Air / Air 020918 020915 020608 020607 220021 4-25
Steel 100 Air / Air 020919 020915 020611 020607 120547 4-26
40 Air / Air 020917 020915 020689 020613 220021 4-27
200 N
2
/ Air 020918 020915 020608 020607 020415 4-28
200 N
2
/ CO
2
020918 020915 020608 020607 020415 4-29
200 H35 / N
2
020920 020915 020608 020607 020415 4-30
100 H35 / N
2
020919 020915 020611 020607 020415 4-31
Aluminum 200 Air / Air 020918 020915 020608 020607 220021 4-32
100 Air / Air 020919 020915 020611 020607 120547 4-33
40 Air / Air 020917 020915 020689 020613 220021 4-34
200 N
2
/ Air 020918 020915 020608 020607 020415 4-35
200 N
2
/ CO
2
020918 020915 020608 020607 020415 4-36
200 H35 / N
2
020918 020915 020608 020607 020415 4-37
100 H35 / N
2
020919 020915 020611 020607 020415 4-38
Mild 200 Air / Air 020891 020882 020615 020607 220021 4-39
Steel 200 H35/Air 020891 020882 020934 020607 020933 4-40
Stainless 200 H35 / N
2
020891 020882 020934 020607 020933 4-41
Steel
Aluminum 200 H35 / N
2
020891 020882 020934 020607 020933 4-42
PAC200T (65°) Cutting Torch Consumables, Torch Assemblies& Torch Leads
The PAC200T (65°) trigger hand torch is option available from Hypertherm. Along with the torch, the associated
conumables, consumable parts kit and torch lead assemblies are described.
Consumables
The consumables listed below are used in the 65° trigger torch for the Cut Charts on the listed pages. Operating
(Cut Chart) parameters are also the same for PAC200T (90°) and PAC200E (gouging) hand torches. Refer to page
d-3 for the consumable parts kit.
