IAI PCON-CA Series User Manual

Chapter 1 Specications Check
POWER CON
PCON-CB/LC
20
1.1.2 Teaching Tool
A teaching tool such as PC software is necessary when performing the setup for position
setting, parameter setting, etc. that can only be done on the teaching tool.
Please prepare either of the following teaching tools.
No. Part Name Model
1
PC Software
(Includes RS232C Adapter + Peripheral Communication Cable)
RCM-101-MW
2
PC Software
(Includes USB Adapter + USB Cable + Peripheral Communication Cable)
RCM-101-USB
3
Touch Panel Teaching TB-01
(Standard Type / Deadman Switch Attached on the Left side Type /
Deadman Switch Attached on the Right side Type)
TB-01/
TB-01D/
TB-01DR
4
Touch Panel Teaching TB-02
(Standard Type / Deadman Switch Type)
TB-02/TB-02D
5 Data Setter TB-03 Wired Link TB-03
1.1.3 Instruction Manuals Related to This Product, which are Contained in
the Instruction Manual (DVD).
No. Name Manual No.
1 PCON-CB/CFB Controller Instruction Manual ME0342
2
PC Software
RCM-101-MW/ RCM-101-USB Instruction Manual
ME0155
3
Touch Panel Teaching TB-01/01D/01DR
Applicable for Position Controller Instruction Manual
ME0324
4
Touch Panel Teaching TB-02/02D
Applicable for Position Controller, ELECYLINDER Instruction Manual
ME0355
5
Data Setter TB-03 Position Controller, ELECYLINDER Wired Link
Instruction Manual
ME0376
6 DeviceNet Instruction Manual ME0256
7 CC-Link Instruction Manual ME0254
8 PROFIBUS-DP Instruction Manual ME0258
9 CompoNet Instruction Manual ME0220
10
MECHATROLINK-Ⅰ/Ⅱ
Instruction Manual
ME0221
11 EtherCAT Instruction Manual ME0273
12 EtherNet/IP Instruction Manual ME0278
13 PROFINET-IO Instruction Manual ME0333
14
MECHATROLINK-Ⅲ
Instruction Manual
ME0317
15 Instruction Manual for the Serial Communication [for Modbus] ME0162
