Chapter 2 Wiring
POWER CON
PCON-CB/LC
38
2.1.2 PIO Pattern Selection and PIO Signal
(1) PIO Pattern (Control Pattern) Selection
The controller provides 8 PIO patterns (Control patterns). Set the most suitable PIO pattern
with the actual use to Parameter No. 25 “PIO Pattern Select”.
Refer to “3.2 Operation in Positioner Mode” for the details of PIO patterns.
Type
Value set in
parameter
No. 25
Mode Overview
PIO
Pattern 0
0
(at the
delivery)
Positioning Mode
(Standard Type)
Number of positioning points : 64 points
Position command : binary code
Zone signal output
*1
: 1 point
(Note 2)
Position zone signal output
*2
: 1 point
(Note 2)
PIO
Pattern 1
1
Teaching mode
(Teaching type)
Number of positioning points : 64 points
Position command : binary code
Position zone signal output
*2
: 1 point
(Note 2)
Jog operation enabled by PIO signal
Writing current position data to position table
enabled by PIO signal
PIO
Pattern 2
2
256-point mode
(Number of positioning
points : 256-point type)
Number of positioning points : 256 points
Position command : binary code
Position zone signal output
*2
: 1 point
(Note 2)
PIO
Pattern 3
3
512-point mode
(Number of positioning
points : 512-point type)
Number of positioning points : 512 points
Position command : binary code
Zone signal output : None
PIO
Pattern 4
4
Solenoid Valve Mode 1
(7-point type)
Number of positioning points : 7 points
Position command : Individual number signal ON
Zone signal output
*1
: 1 point
(Note 2)
Position zone signal output
*2
: 1 point
(Note 2)
PIO
Pattern 5
5
Solenoid Valve Mode 2
(3-point type)
Number of positioning points : 3 points
Position command : Individual number signal ON
Completion signal : Signal equivalent to LS
(limit switch) enabled
Zone signal output
*1
: 1 point
(Note 2)
Position zone signal output
*2
: 1 point
(Note 2)
PIO
Pattern 6
(Note 1)
6
Pulse Train Control
Mode for Incremental
[Refer to 2.2]
Differential pulse input (MAX. 200kpps)
Home return function
Zone signal output
*1
: 2 point
No feedback pulse output
PIO
Pattern 7
(Note 1)
7
Pulse Train Control
Mode for Absolute
[Refer to 2.2]
Setting the datum point (1 places)
Differential pulse input (MAX. 200Kpps)
Home return function
Zone signal output
*1
: 2 point
No feedback pulse output
*1 Zone signal output : Zone range is to be set to either Parameter No.1, 2 or No.23, 24 and it
is always available after the home-return operation is complete.
*2
Position zone signal output
: This feature is associated with the specified position number. The zone
range is set in the position table. The zone range is enabled only when
the position is specified but disabled if another position is specified.
Note 1 Pulse Train Control Mode is available only if the pulse train control type is indicated (from
PCON-CB-*-PLN and PLP) at the purchase.
Note 2 Position Zone Signal can be switched over to Zone Signal with the setting of Parameter
No.149.
