Chapter 1 Specications Check
POWER CON
PCON-CB/LC
32
1.4.2
Pulse T
rain Input Output Interface
Line Driver Input
S
pecification
Sends input pulse (dif
ferential voltage: approx. 4V) from the host
unit that is installed with a line drive
r 26C31 or equivalent
Host Unit
Positioning Unit
PCON
PP
/PP
NP
/NP
Pulse T
rain
Form
Including active high and active low
45
47
