92
Part 2 Programs
SEL language consists of a position part (position data = coordinates, etc.) and a command part
(application program).
2. Position Part
As position data, coordinates, speeds, accelerations and decelerations are set and stored.
Position No. Axis 1 Axis 2 Speed Acceleration Deceleration
1
2
3
1498
1499
1500
*1 Varies depending on the actuator model.
*2 If speed, acceleration or deceleration is set in the position data, the setting will be given priority over
the corresponding data set in the application program. Leave the position data fields empty if you
wish to enable the corresponding data in the application program.
Priority Speed Acceleration
1 Setting value for the position data in the operation 1 Setting value for the position data in
the operation 1
2 Setting value for VEL directive Setting value for ALL (DLL) direction
3 Initial value for all axes parameter No.
11 acceleration (Initial value for all
axes parameter No. 12 deceleration)
Values pertaining to a rotating axis are processed in degrees instead of millimeters.
If axis-specific parameter No. 1 (axis operation type) is set to “1” (rotational movement axis (angle
control)) for a given axis, all millimeter values pertaining to that axis (including parameters, etc.) will be
processed in degrees.
If the gear ratio parameters (axis-specific parameter Nos. 50 and 51) are set correctly, the angles (deg)
will represent those of the body of rotation at the end.
Example) Distance 1 mm 1 deg
Speed 1 mm/sec 1 deg/sec
Acceleration/deceleration 1 G = 9807 mm/sec
2
9807 deg/sec
2
2000000.000 mm
*1, 2
1 ~ 2000/mmsec
*2
Standard
0.3 G
*2
Standard
0.3 G
