Table 4. SPCN Error Codes for the CEC (system unit) (continued)
Error Code Description Action/
Possible Failing FRU
1011 7620 System fan 2 fault Fan 2
Location:
U0.1-F2
1011 7621 System fan 2 missing Fan 2
Location:
U0.1-F2
1011 7626 Power supply 1 fan missing System drawer power supply 1
Location: U0.1-V1
1011 7630 System fan 3 fault Fan 3
Location: U0.1-F3
1011 7631 System fan 3 missing Fan 3
Location: U0.1-F3
1011 8400 Invalid configuration decode Go to “MAP 1540: Problem Isolation Procedures”
on page 110.
1011 8401 VPD access problem Go to “MAP 1540: Problem Isolation Procedures”
on page 110.
1011 8402 VPD concentrator fault Service processor card
Location:
U0.1-P1-X1
1011 8403 VPD level mismatch
1. System VPD module
Location:
U0.1-L1-N1
2. Service processor card
Location:
U0.1-P1-X1
1011 8404 VPD mismatch System backplane
Location:
U0.1-P1
1011 8405 VPD mismatch System backplane
Location:
U0.1-P1
1011 8406 VPD mismatch System backplane
Location:
U0.1-P1
1011 8409 No processors installed System backplane
Location:
U0.1-P1
1011 840A VPD: 5V won’t turn off Go to “MAP 1540: Problem Isolation Procedures”
on page 110.
1011 840B VPD: 5V won’t turn on Go to “MAP 1540: Problem Isolation Procedures”
on page 110.
1011 840C Memory DIMM(s) are not properly installed Verify that all of the memory DIMMs are properly
installed and seated.
1011 840D SPCN configuration fault
1. Check the SPCN cabling.
2. Set the I/O type. See the“″Power Control
Network Utilities Menu″ on page ” on page
241.
3. Replace the service processor card, location:
U0.1-P1-X1.
1011 840E SPCN default configuration loaded
1. Check the SPCN cabling.
2. Set the I/O type. See the“″Power Control
Network Utilities Menu″ on page ” on page
241.
3. Replace the service processor card, location:
U0.1-P1-X1.
Chapter 5. Error Code to FRU Index 169
