Table
6.
Service
Processor
Error
Codes.
(continued)
Error
Code
Description
Action/
Possible
Failing
FRU
4503
30D3
Description:
1
GB
DIMM
fault
Action:
This
error
code
indicates
that
the
memory
repeat
gard
function
has
deconfigured
a
quad
of
memory.
Do
the
following:
1.
Go
to
the
memory
configuration/deconfiguration
menu,
located
under
the
system
information
menu
in
the
service
processor
menus.
Look
at
the
status
of
the
DIMMs.
If
any
of
the
DIMMs
have
a
status
of
manually
deconfigured,
reconfigure
the
DIMMs
and
boot
the
system
to
the
SMS
menus.
Power
off
the
system
using
the
white
power
button
and
look
again
at
the
status
of
the
DIMMs.
If
all
of
the
processors
are
still
configured
in
the
processor
configuration/deconfiguration
menu,
the
problem
has
been
resolved.
If
all
of
the
DIMMs
are
still
configured
in
the
memory
configuration/deconfiguration
menu,
the
problem
has
been
resolved.
If
any
of
the
DIMMs
have
a
status
of
deconfigured
by
the
system,
either
before
or
after
the
boot
to
the
SMS
menus,
go
to
step
2.
2.
Replace
the
quad
of
memory
containing
the
DIMM
specified
by
the
location
code.
The
entire
quad
of
memory
must
be
replaced.
4503
30D4
Description:
1
GB
DIMM
fault
Action:
This
error
code
indicates
that
the
memory
repeat
gard
function
has
deconfigured
a
quad
of
memory.
Do
the
following:
1.
Go
to
the
memory
configuration/deconfiguration
menu,
located
under
the
system
information
menu
in
the
service
processor
menus.
Look
at
the
status
of
the
DIMMs.
If
any
of
the
DIMMs
have
a
status
of
manually
deconfigured,
reconfigure
the
DIMMs
and
boot
the
system
to
the
SMS
menus.
Power
off
the
system
using
the
white
power
button
and
look
again
at
the
status
of
the
DIMMs.
If
all
of
the
processors
are
still
configured
in
the
processor
configuration/deconfiguration
menu,
the
problem
has
been
resolved.
If
all
of
the
DIMMs
are
still
configured
in
the
memory
configuration/deconfiguration
menu,
the
problem
has
been
resolved.
If
any
of
the
DIMMs
have
a
status
of
deconfigured
by
the
system,
either
before
or
after
the
boot
to
the
SMS
menus,
go
to
step
2.
2.
Replace
the
quad
of
memory
containing
the
DIMM
specified
by
the
location
code.
The
entire
quad
of
memory
must
be
replaced.
4503
30D5
Description:
2
GB
DIMM
fault
Action:
This
error
code
indicates
that
the
memory
repeat
gard
function
has
deconfigured
a
quad
of
memory.
Do
the
following:
1.
Go
to
the
memory
configuration/deconfiguration
menu,
located
under
the
system
information
menu
in
the
service
processor
menus.
Look
at
the
status
of
the
DIMMs.
If
any
of
the
DIMMs
have
a
status
of
manually
deconfigured,
reconfigure
the
DIMMs
and
boot
the
system
to
the
SMS
menus.
Power
off
the
system
using
the
white
power
button
and
look
again
at
the
status
of
the
DIMMs.
If
all
of
the
processors
are
still
configured
in
the
processor
configuration/deconfiguration
menu,
the
problem
has
been
resolved.
If
all
of
the
DIMMs
are
still
configured
in
the
memory
configuration/deconfiguration
menu,
the
problem
has
been
resolved.
If
any
of
the
DIMMs
have
a
status
of
deconfigured
by
the
system,
either
before
or
after
the
boot
to
the
SMS
menus,
go
to
step
2.
2.
Replace
the
quad
of
memory
containing
the
DIMM
specified
by
the
location
code.
The
entire
quad
of
memory
must
be
replaced.
450x
26F4
System
backplane
with
1
processor
fault
Replace
the
CEC
backplane
Location:
U0.1-P1
450x
26F5
System
backplane
with
2
processors
fault
Replace
the
CEC
backplane
Location:
U0.1-P1
Chapter
5.
Error
Code
to
FRU
Index
197
