Reference
Code
Description/Action
(Perform all actions before exchanging Failing
Items)
Failing Item
0F13 Unidentified box ID. Code type mismatch.
The SPCN node cannot determine the machine
type of the box in which it is installed. If not able
to fix, go to “MAP 1540: Minimum Configuration”
on page 117.
1. SPCN card
Location: U1.1-P2-X1
2. System backplane assembly
Location: U1.1-P1
0F1F Unidentified box ID. LCD test failed.
The SPCN node cannot determine the machine
type of the box in which it is installed. If not able
to fix, go to “MAP 1540: Minimum Configuration”
on page 117.
1. SPCN card
Location: U1.1-P2-X1
2. System backplane assembly
Location: U1.1-P1
0F2C Unknown box ID.
The SPCN node cannot determine the machine
type of the box in which it is installed. If not able
to fix, go to “MAP 1540: Minimum Configuration”
on page 117.
1. SPCN card
Location: U1.1-P2-X1
2. System backplane assembly
Location: U1.1-P1
0F2D Unknown box ID. Code level mismatch.
The SPCN node cannot determine the machine
type of the box in which it is installed. If not able
to fix, go to “MAP 1540: Minimum Configuration”
on page 117.
1. SPCN card
Location: U1.1-P2-X1
2. System backplane assembly
Location: U1.1-P1
0F2E SPCN network fault.
The box ID was not defined. A network
communications failure occurred. If not able to fix,
go to “MAP 1540: Minimum Configuration” on
page 117.
1. SPCN card
Location: U1.1-P2-X1
2. System backplane assembly
Location: U1.1-P1
1100 Power supply P01 error
A fault detection failure occurred for power supply
P01. If the LED on a bulk power supply is not on
or is blinking, it may be the failing item. The LED
not on may be the only indication of a failure.
Exchange the bulk power supply to correct this
problem.
1. Bulk power supply P01
Location: U1.2-V1
2. SPCN card assembly R21
Location: U1.1-P2-X1
1101 Power supply P02 error
A fault detection failure occurred for power supply
P02. If the LED on a bulk power supply is not on
or is blinking, it may be the failing item. The LED
not on may be the only indication of a failure.
Exchange the bulk power supply to correct this
problem.
1. Bulk power supply P02
Location: U1.2-V2
2. SPCN card assembly R21
Location: U1.1-P2-X1
1xxx
Chapter 5. Error Code to FRU Index 191
