Reference
Code
Description/Action
(Perform all actions before exchanging Failing
Items)
Failing Item
1102 Power supply P03 error
A fault detection failure occurred for power supply
P03. If the LED on a bulk power supply is not on
or is blinking, it may be the failing item. The LED
not on may be the only indication of a failure.
Exchange the bulk power supply to correct this
problem.
1. Bulk power supply P03
Location: U1.2-V3
2. SPCN card assembly R21
Location: U1.1-P2-X1
1103 Power supply P04 error
A fault detection failure occurred for power supply
P04. If the LED on a bulk power supply is not on
or is blinking, it may be the failing item. The LED
not on may be the only indication of a failure.
Exchange the bulk power supply to correct this
problem.
1. Bulk power supply P04
Location: U1.2-V4
2. SPCN card assembly R21
Location: U1.1-P2-X1
1104 Power supply P05 error
A fault detection failure occurred for power supply
P05. If the LED on a bulk power supply is not on
or is blinking, it may be the failing item. The LED
not on may be the only indication of a failure.
Exchange the bulk power supply to correct this
problem.
1. Bulk power supply P05
Location: U1.2-V5
2. SPCN card assembly R21
Location: U1.1-P2-X1
1108 Regulator R01 error
A fault detection failure occurred for regulator
R01.
1. Programmable regulator assembly R01
Location: U1.1-P2-V1
2. SPCN card
Location: U1.1-P2-X1
1109 Regulator R02 error
A fault detection failure occurred for regulator
R02.
1. Programmable regulator assembly R02
Location: U1.1-P2-V2
2. SPCN card
Location: U1.1-P2-X1
110A Regulator R03 error
A fault detection failure occurred for regulator
R03.
1. Programmable regulator assembly R03
Location: U1.1-P2-V3
2. SPCN card
Location: U1.1-P2-X1
110B Regulator R04 error
A fault has been detected for regulator R04.
1. Programmable regulator assembly R04
Location: U1.1-P2-V4
2. SPCN card
Location: U1.1-P2-X1
110C Regulator R05 error
A fault detection failure occurred for regulator
R05.
1. Programmable regulator assembly R05
Location: U1.1-P2-V5
2. SPCN card
Location: U1.1-P2-X1
1xxx
192
Service Guide
